MoFi Electronics just launched a new series of loudspeakers in collaboration with the legendary speaker designer Andrew Jones. This series includes the SourcePoint V10 Master Edition loudspeakers, MoFi’s new flagships. These speakers feature twin 10-inch woofers and dual rear-firing passive radiators, combining to make a three-way tower speaker. The V10 Master Edition retails for £8,800 per pair, with additional magnetic grilles selling for £270.
Overview
The design
The SourcePoint V10 Master Editions come in two real-wood veneer finishes, Walnut and Black Ash. With your purchase, you have the option to get black or grey magnetic grilles for an extra £270.
The cabinets are book-matched and sealed with a satin coat to bring out the natural grain. The one-inch-thick closed cabinets use SourcePoint’s multi-faceted baffle, which uses angled planes around each driver to reduce diffraction and reflections. Each woofer and passive radiator sits in its own isolated chamber to reduce cabinet resonance and maximise bass output.
The drivers
For the V10 Master Editions, Andrew Jones expanded upon the original two-way SourcePoint 10 loudspeakers and added dual 10-inch woofers and two 10-inch passive radiators. The V10’s three-way system allows each driver to handle a dedicated range of frequencies, and leaves the 10-inch concentric driver to focus on the midrange and treble.
The crossover
The SourcePoint V10 Master Edition loudspeakers also get a new built-in tunable crossover network. This allows you to adjust the speaker’s HF output and user preferences with position switches on the rear of the speaker. The phase alignment ensures the handoff between the drivers is smooth, and the result is a sound signature that gives you complete control over your speakers.
Further information: MoFi Electronics
Key features
- 3-way passive radiator design featuring a concentric 10-inch midrange and 1.25-inch soft-dome tweeter for wide, even sound dispersion
- Dual 10-inch paper-cone woofers and twin rear-firing passive radiators deliver deep, articulate bass response down to 27 Hz
- Available in genuine Walnut or Black Ash real-wood veneer with book-matched grain patterns and satin clear coat finish
- Master Edition crossover network uses premium polypropylene film capacitors, metalized-film resistors, and air-core inductors for minimal distortion
- Multi-chambered cabinet construction with sculpted, multi-faceted baffle reduces cabinet resonance and edge diffraction
- Tunable tweeter allows fine-tuning of high-frequency response to match room acoustics and personal preference
- One-inch-thick closed cabinet design with isolated driver chambers maximizes rigidity and bass performance
Technical specifications
- Frequency Range: 27 Hz – 30 kHz
- Sensitivity: 91 dB (2.83 V / 1 m)
- Nominal Impedance: 6 Ohms (4.5 Ohms minimum)
- Max Power Handling: 200 Watts
- Crossover Frequencies: 130 Hz, 1.4 kHz
- System Type: 3-way passive radiator with concentric driver
- Tweeter: 1.25″ soft dome (tunable)
- Midrange: 10″ paper cone
- Woofers: 2 × 10″ paper cone
- Passive Radiators: 2 × 10″
- Finishes: Walnut, Black Ash
- Dimensions (H × W × D): 48.8″ × 15.5″ × 19.9″
- Weight: 160 lbs per speaker
